Advance LC1420CI 120 VAC 60 Hz 14 W 1-Lamp T12 Magnetic Ballast

idw

Product Data

• Bar code on pack: 781087101308
• Short product name: MAG BALLAST (1) F20T12 PH 120V
• Product number: LC1420CI
• Full product name: MAG BALLAST (1) F20T12 PH 120V
• Pieces per Sku: 1
• Logistics code(s): 913710305701
• eop_net_weight_pp: 0.323 kg
• eop_pck_cfg: 12
• Skus/Case: 12
• Bar code on case: 30781087101309

General Characteristics

• Ballast Type: Magnetic Fluorescent
• Number of Lamps: 1 piece
• Family Name: Standard
• Input Voltage: 120 V
• Starting Method: Preheat
• Input Current (Operating): 0.33 A
• Line Frequency: 60 Hz
• Housing: C2
• Lamp Type: F20T12
• Housing Material: Metal
• Base Model: LC1420C
• Suitable for Outdoor use?: Yes
• Housing Dimensions: 1.06" x 1.59" x 1.81"

Approval & Application Chars

• UL Recognized: No
• CSA E: No
• NOM certificate: No
• FIDE Certificate: No
• RoHS Compliant: Yes
• SASO Certificate: No
• Circle E logo: No
• cUL certificate: No
• UL Listed: Yes
• DOE: No
• CSA certificate: Yes
• EMC Immunity: FCC Non-Consumer
• CEC Listing: No
• Approbation Marks: UL, CSA, RoHS

Operating Characteristics

• Ballast factor: 0.93 -
• Power Factor: 0.52
• Inp. Current (Open Circuit): 0
• Input Power Gear: 21 W
• Sound Rating: A
• Ballast Efficacy Factor: 4.5 -
• Ignition time: 1 s
• Input Current (Starting): 0.36
• Lamp Current Crest Factor: 1.5 -
• Max THD: 10 %
• Automatic restart: Yes

Product Dimensions

• Width B1: 1.81 in
• Length A1: 3.06 in
• Length A2: 2.75 in
• Height C1: 1.59 in
• Fixing Hole Diameter D1: 0.19 in

Wiring Characteristics

• Wire Length by Color: See data sheet
• Wire Gauge: 18AWG
• Lamp Connection: Series
• Allowed Wiring Config(Remote): Yes
• Allowed Wiring Config(Tandem): No
• Max Dist. Ball to Lamp(Remote): 30'
• Wire Striplength: 0.50/0.375 mm
• Allowed Wiring Config(Through): No
• Wire Type: Solid

System Chars On Driver Level

• Rated Lamp Watts: 20W
